ASTM A 453 GR 660 Class D Bolts Manufacturer and Supplier in Houston , USA

Request For Our Latest Prices On ASTM A 453 GR 660 Class D Bolts in Houston , USA!

Brian Fasteners, Houston, USA, is a reliable fastener manufacturer and supplier located in Houston, USA, having expertise in providing high-grade ASTM A 453 GR 660 Class D bolts. Well known for their precision engineering and reliability, the bolts are intended to satisfy demanding industrial standards. With a drive to excellence, Brian Fasteners provides trustworthy fastening solutions suitable for harsh environments. Their experience in manufacturing ASTM A 453 GR 660 Class D bolts positions them as a go-to company for sectors demanding high strength and anti-corrosion properties, with products that improve performance and safety across a range of applications.

ASTM A 453 Gr 660 Class D Bolts in California, SS ASTM A 453 Serrated Flange Bolts in Los Angeles, ASTM A453 Gr 660 Nylon Lock Bolts in Houston , ASTM A 453 Gr 660 Class D Custom Bolts in California, ASTM A 453 Grade 660 Class D Heavy Bolts in Texas, ASTM A 453 Gr 660 Class D Bolts Supplier in Houston , USA.

ASTM A 453 GR 660 Class D bolts consist mainly of high-strength alloy steel, precision heat-treated to realize maximum mechanical properties. These bolts have superior tensile strength, generally 110 ksi, and yield strength at approximately 90 ksi, guaranteeing ruggedness with heavy loads. Their higher toughness and resistance to stress corrosion cracking render them favorable for critical structural applications. The accurate chemical content contains carbon, manganese, chromium, and molybdenum, which accounts for their superior hardness and fatigue resistance, vital for stringent industrial applications.

ASTM A 453 GR 660 Class D Bolts Specifications

Material	Dimensions	Standards	Size	Length
ASTM A453 GR 660 CLASS D Bolts	ASME B18.2.1, B18.3	ASTM, ASME	M 02 to M 160	3 mm to 200 mm

ASTM A453 Gr 660 Set Screw, Gr 660 Class D Hex Bolts, ASTM A 453 Tie Rod, Gr 660 Class D Tie Bar, ASTM A453 Grade 660 Class D Bolts Stockist in Houston , USA.

ASTM A 453 GR 660 Class D Bolts Chemical Composition

Element	Content
Carbon	0.08 max
Manganese	2.00 max
Phosphorus, max	0.040 max
Sulfur, max	0.030 max
Silicon	1.00 max
Nickel	24.0-27.0
Chromium	13.5-16.0
Molybdenum	1.00-1.50
Tungsten	–
Titanium	1.9-2.35
Aluminum	0.35 max
Vanadium	0.10-0.50
Boron	0.001-0.010

ASTM A 453 GR 660 Class D Bolts Mechanical Properties

Tensile Strength/Ultimate Tensile Stress (UTS) – (Mpa)	895 min
Yield Strength/Proof Stress(0.2% Offset) (YS) – (Mpa)	585 min
Elongation in 4D (El)	15
Reduction	18

SS UNS S20910 Serrated Flange Bolts in Texas, ASTM A 453 GR 660 Class D Bolts Supplier in Houston , ASTM A 453 GR 660 Class D Bolts in Los Angeles, ASTM A 453 Gr 660 Class D Bolt in California, ASTM A 453 Tie Rod in California, Gr 660 Class D Tie Bar in Houston , USA.

Commited to High Quality Service

To satisfy our clients needs by providing high quality products at competitive price as per the schedule and to maintain long term relationship with our clients.

ASTM A 453 GR 660 Class D bolts find extensive application in the power generation industry, petrochemical industry, and heavy machinery industry. The bolts are suitable for clamping components in pressure vessels, boilers, and flanges because they have high strength and thermal and mechanical stress resistance. The bolts guarantee safety and integrity in critical facilities like refineries and power plants. Their consistent performance at high stress conditions renders them invaluable for use in durability and corrosion needs over the long term, imparting confidence in structural stability and performance efficiency.

LARGEST INVENTORY

ON TIME DELIVERIES

CUSTOMER SUPPORT

Types of ASTM A 453 GR 660 Class D Bolts

At Brian Fasteners, we prioritize the safety and quality of our ASTM A 453 GR 660 Class D bolts during shipping. Each bolt is thoroughly inspected and individually tightened to prevent damage. We pack them in hard labeled boxes that clearly show product details and quantities. These meticulous packaging ensures that our bolts remain in pristine condition, ready to meet the demanding demands of high temperatures and high pressures upon arrival the solution of the.
