Home > Hastelloy C276 Stud Bolts
Request For Our Latest Prices On Hastelloy C276 Stud Bolts in Houston , USA!
At Brian Fasteners, our Hastelloy C276 Stud Bolts are designed for superior performance in the toughest environments. Known for their outstanding resistance to severe corrosion, oxidation, and high temperatures, these stud bolts are excellent in chemical applications, petrochemical applications, and marine applications in and their exceptional strength and durability ensure long-term reliability and low maintenance. Designed to withstand harsh conditions, Hastelloy C276 Stud Bolts are ideal for critical industrial applications where performance and safety are paramount.
Based in Houston, USA, Brian Fasteners is a reputable producer and supplier of high-quality Hastelloy C276 Stud Bolts that are designed to last and perform exceptionally well in the most demanding industrial settings. Our stud bolts are made to the highest international standards and are intended to endure severe corrosion, heat, and pressure. These fasteners are expertly crafted for maximum reliability, making them perfect for applications involving chemical processing, marine environments, and power generation. Brian Fasteners has established an excellent reputation for offering clients in a variety of high-demand industries cutting-edge fastening solutions by prioritising quality, custom specifications, and timely delivery.
| Specifications | ASTM B574 / ASME SB574 |
|---|---|
| Fasteners size | Bolt / Screw Size : M3 – M56 | 3/6″ to 2″ | Custom Sizes Nuts Size : M3 – M56 | 3/6″ to 2″ | Custom Sizes Washers Size : M3 – M56 | 3/6″ to 2″ | Custom Sizes Machine Screws Size : M1.6 – M12 Self Tapping Screw Size : No.2 – No. 14 |
| Fasteners Length | 3 mm to 200 mm |
| Fastener Threads | UNF, BSW, BSF, METRIC, UNC or as required |
| Standard of High Nickel Alloy Fasteners | DIN : DIN 934, DIN 931, DIN 970, DIN 933 UTS : UNEF, NPT, UNC, UNS, UNF, NPTF ISO : JIS standards, ISO 4033, ISO 4032, ANSI – American National Standards Institute ASME B18.5 ANSI B 28.2.4 1M as per defined in ASME B16.5 standard Stud Bolt length ANSI B 18.2.4 2M as per defined in ASME B18.2.2 Hex nuts |
| Dimensions | DIN 931, 933, 934, 7991, 976, 125, ASME B18.2.1, B18.3 |
| Surface Coating | Ptfe Coated High Nickel Alloy Fasteners Phosphate Coating Teflon Coating Zinc Coating Hot Dipped Galvanizing Coating Cadmium Coating Xylon Coating |
| Fasteners Finishing | High Nickel Alloy : Self-Colour, Passivated, Bright Zinc Plated (BZP), Hot Dip Galvanised (HDG), High Nickel Alloy, Sherardized, some special one like DACROMET Geometry and Mechanically Applied coating ,Dacroment, nickel plated, anodizing, plated zinc-nickel Zinc (blue, black, yellow, white), black oxide. |
| Grade | C | Mn | Si | Co | S | Ni | Cr | Fe | Mo | W | V | P |
| Hastelloy C276 Stud Bolts | 0.010 max | 1.0 max | 0.08 max | 2.5 max | 0.03 max | Bal | 14.5 – 16.5 | 4 – 7 | 15 – 17 | 3 – 4.5 | 0.35 max | 0.04 max |
| Element | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| Hastelloy C276 Stud Bolts | 8.89 g/cm3 | 1370 °C (2500 °F) | Psi – 1,15,000 , MPa – 790 | Psi – 52,000 , MPa – 355 | 40 % |
To satisfy our clients needs by providing high quality products at competitive price as per the schedule and to maintain long term relationship with our clients.
The main component of Hastelloy C276 Stud Bolts is nickel (about 57%), followed by molybdenum (15–17%), chromium (14.5–16.5%), iron (4–7%), and trace amounts of cobalt and tungsten. Strong oxidisers, chlorides, and reducing agents are just a few of the chemical environments to which this alloy exhibits remarkable resistance. With a minimum tensile strength of roughly 690 MPa, a yield strength of roughly 283 MPa, and an elongation of up to 40%, these bolts exhibit exceptional mechanical performance. They are appropriate for demanding industrial processes because they retain their structural integrity in the face of high temperatures and corrosive environments.
Applications needing exceptional mechanical strength and resistance to corrosion frequently use Hastelloy C276 Stud Bolts. They protect machinery like scrubbers that deal with aggressive media, heat exchangers, columns, and reactors, which are frequently used in chemical processing facilities. These bolts are resistant to biofouling and saltwater corrosion in offshore and marine settings. Additionally, they are essential in pulp and paper mills, flue gas desulfurization units, and pollution control systems. They are used for high-temperature and high-pressure systems in power generation facilities. Long-lasting, leak-proof fastening in crucial, safety-sensitive industrial assemblies is ensured by their resilience to thermal cycling and chemical attack.
Brian Fasteners is a leading manufacturer and supplier of high-quality fasteners in Houston , USA, with over 8 years of experience serving global industries.
