Request For Our Latest Prices on Monel K500 Stud Bolts in Houston , USA!
Brian Fasteners is a leading Houston, USA-based manufacturer and supplier of top-grade industrial fasteners such as Monel K500 Stud Bolts. With technical know-how and years of experience, we provide fasteners conforming to strict international quality standards and handling tough conditions with ease. Our Monel K500 Stud Bolts are renowned throughout industries for their durability, accuracy, and resistance to harsh conditions. For marine engineering, chemical processing, or aerospace, Brian Fasteners offers high-performance fastening solutions that meet the needs of individual customers. Our sophisticated manufacturing process and attention to quality guarantee on-time delivery and regular dependability with each order.
Monel K500 Stud Bolts consist mainly of nickel (63%) and copper (27-33%) with a reinforcement of aluminum (2.3-3.15%) and titanium (0.35-0.85%) for added strength. These alloyed fasteners possess good corrosion resistance, especially in chemical and marine environments. They mechanically contain high tensile strength (up to 160 ksi), yield strength (up to 110 ksi), and good fatigue resistance. Their hardness is between Rockwell B88–C32. Aging treatment during manufacture enhances mechanical stability without reducing corrosion performance, thus suiting them for high-stress applications.
| Element | Content (%) |
| Nickel, Ni | 63.0-70.0 |
| Silicon, Si | .50 max |
| Carbon, C | .25 max |
| Sulphur, S | .01 max |
| Copper, Cu | – |
| Iron, Fe | 2.0 max |
| Manganese, Mn | 1.5 max |
| Properties | Metric | Imperial |
| Tensile strength(annealed) | 517-620 MPa | 75-90 ksi |
| Yield strength | 172-345 MPa | 25-50 ksi |
| Modulus of elasticity | 179 GPa | 26000 ksi |
| Poisson’s ratio | 0.32 | 0.32 |
| Specification | ASTM B865, F467 / ASME SB865, SF467 |
| Standard | all International Standards and ASTM, DIN, BS |
| Size | M3 – M56 | 3/6″ to 2″ | Custom Sizes |
| Length | 3 mm to 200 mm | Custom Sizes |
| DIN Standard | DIN 931, DIN 933, DIN 912, DIN 934, DIN 6923, DIN 603, DIN 7981, DIN 970, DIN916, DIN 7982, DIN 7985, DIN 913 |
| Form | Hex, Threading, Square, Round as per Gauge Etc. |
| Threads | Unless otherwise specified, the threads shall be rolled or cut and tapped horizontally or vertically |
| Threads available | UNF, BSW, BSF, METRIC, UNC, or as required |
| Threads Configuration | ASME B1.1 2A/3A – 2B/3B Inch Unified Threads and B1.13M 6h-6G Metric Coarse Threads |
| UTS | NPT, UNS, UNF, UNC, UNEF, NPTF |
| Test Certificate | As per EN 10204 / 3.1 Manufacturer Test Certificate, PED 97/23/EC Certified, Merkblatt AD 2000 W2 Certified |
| ISO | ISO 4033, ISO 4032, ISO 7380, ISO 4017, JIS standards |
| Threads | METRIC, BSW, UNC, UNF, BSF or as required |
| Surface Coating | Cadmium Coating Hot Dipped Galvanizing Coating Ptfe Coated Phosphate Coating Teflon Coating Xylon Coating Zinc Coating |
To satisfy our clients needs by providing high quality products at competitive price as per the schedule and to maintain long term relationship with our clients.
Monel K500 Stud Bolts are extensively applied in applications where propertiness and corrosion resistance are imperative. In marine environments, they best suit propeller shafts, pump shafts, and underwater bolts because of superior seawater resistance. Chemical process plants employ them as pumps, valves, and heat exchangers in service to corrosive chemicals. They also find application in oil and gas sectors for offshore drilling platforms and sour gas facilities. Aerospace parts and nuclear reactors are helped by their mechanical stability and resistance to high-temperature corrosion. They are reliable in safety–critical situations due to their durability and anti–sparking attributes.
Monel K500 stud bolts are packaged in a way that is most protective to avoid any harm in the course of delivery by Brian Fasteners. Every stud bolt is thoroughly inspected and the item is well protected to ensure it is not affected by moisture during transportation. Special packaging services can be provided to fit the customer requirements so that the stud bolts are received in the best possible condition and are usable from the moment they are received.
Brian Fasteners is a leading manufacturer and supplier of high-quality fasteners in Houston , USA, with over 8 years of experience serving global industries.
