Request For Our Latest Prices on Stainless Steel 304H Nuts in Houston , USA!
Brian Fasteners, located in Houston, USA, is a reputable manufacturer and supplier of top-notch Stainless Steel 304H Nuts. Known for their dedication to quality and precision, Brian Fasteners caters to a diverse array of industries, providing products that adhere to strict international standards. Their Stainless Steel 304H Nuts are designed to deliver exceptional strength, corrosion resistance, and durability, making them perfect for demanding applications. With a strong emphasis on customer satisfaction, prompt delivery, and reliable products, Brian Fasteners has established itself as a go-to partner for clients in search of premium fastening solutions throughout the United States and beyond.
These Stainless Steel 304H Nuts are primarily made of iron, featuring 18–20% chromium, 8–11% nickel, and a higher carbon content (0.04–0.10%) compared to standard 304, which boosts their high-temperature strength. They boast impressive mechanical properties, including a tensile strength of around 515 MPa, yield strength of 205 MPa, and an elongation of 40% over 50 mm. The increased carbon content enhances creep resistance, making them well-suited for high-temperature settings. Moreover, Stainless Steel 304H is known for its good toughness and corrosion resistance, particularly in oxidizing environments, ensuring long-lasting performance even under thermal stress and challenging conditions.
| Grade | C | Mn | Si | P | S | Cr | Mo | Ni | N | |
|---|---|---|---|---|---|---|---|---|---|---|
| 304H | min. | 0.04 | – | – | – | – | 18.0 | – | 8.0 | – |
| max. | 0.10 | 2.0 | 0.75 | 0.045 | 0.030 | 20.0 | – | 10.5 | – | |
| Grade | Tensile Strength (MPa) min | Yield Strength 0.2% Proof (MPa) min | Elongation (% in 50mm) min | Hardness | |
|---|---|---|---|---|---|
| Rockwell B (HR B) max | Brinell (HB) max | ||||
| 304H | 515 | 205 | 40 | 92 | 201 |
| Specifications | DIN, ISO ,JIS ,GB, IS, BS, ASTM |
| Standard | ASTM A193 / A194, ASME SA193 / SA194 |
| Size | M2 – M100 |
| Length | 3 mm to 200 mm | Custom Sizes |
| Dimensions Standard | DIN: DIN931, 933, 934, 7991, 976, 125 ISO: ISO 4033, 4032 ASME B18.5, B18.3 |
| Form | Hex, Threading, Square, Round as per Gauge Etc. |
| Threads | Unless otherwise specified, the threads shall be rolled or cut and tapped horizontally or vertically |
| Threads available | UNF, BSW, BSF, METRIC, UNC, or as required |
| Threads Configuration | ASME B1.1 2A/3A – 2B/3B Inch Unified Threads and B1.13M 6h-6G Metric Coarse Threads |
| Certification | Dual Certified As per ASTM & ASME Codes |
| Test Certificate | As per EN 10204 / 3.1 Manufacturer Test Certificate, PED 97/23/EC Certified, Merkblatt AD 2000 W2 Certified |
To satisfy our clients needs by providing high quality products at competitive price as per the schedule and to maintain long term relationship with our clients.
Stainless Steel 304H Nuts are widely utilized across various industries due to their outstanding mechanical and corrosion-resistant characteristics. These nuts are perfect for high-temperature applications, commonly found in power plants, chemical processing equipment, heat exchangers, and boilers. Their enhanced strength and oxidation resistance make them ideal for use in petroleum refineries, gas turbines, and superheater components. In the construction industry, they are employed in structural frameworks that are exposed to heat or corrosive environments. Additionally, their durability and reliability make them essential in marine applications, food processing equipment, and other demanding industrial operations.
We ensure that we have complete documentation for our Stainless Steel 304H nuts. Commercial invoices, packaging documents, heat treatment charts, quality control charts, and NABL-approved reports on laboratory testing are included. Our commitment to quality extends to issuing various test certificates and our 304H products, such as MTC according to EN 10204/3.1b, PMI test certificate, and 100% radiography test report. To further strengthen customer satisfaction, we offer third-party inspection certificates, which prove our fruit’s quality and reliability for various applications and durability.
