Request For Our Latest Prices On Duplex Steel Stud Bolts S32205 in Houston , USA!
Brian Fasteners, one of the best fastener producers and suppliers located in Houston, USA, provides superior-quality Duplex Steel Stud Bolts S32205 for severe industrial uses. The stud bolts are acknowledged for their superior strength, corrosion resistance, and endurance in harsh environments. They are produced from Duplex UNS S32205 and are suitable for application in marine, oil & gas, and chemical processing industries. Our S32205 stud bolts are produced to specifications of ASTM A182 and A479, guaranteeing high performance and consistency. At Brian Fasteners, technical precision and quality assurance come together to provide fasteners designed for severe service conditions.
Duplex S32205 is a nitrogen-strengthened duplex stainless steel containing about 22% chromium, 5–6.5% nickel, 3–3.5% molybdenum, and the balance iron. The microstructure is almost equal amounts of austenite and ferrite. This alloy provides it with superior resistance against pitting, stress corrosion cracking, and general corrosion. S32205 stud bolts have tensile strength of 95–115 ksi, yield strength of 65–80 ksi, and Rockwell hardness up to B100. Their high strength-to-weight ratio and resistance to corrosion render them a suitable option for hostile environments.
| S32205 | C | N | P | Si | Mn | Mo | Fe | Cr | S | Ni |
| 1.0 | 0.03 | 0.02 | 2.0 | 3.0 – 3.5 | 22.0 – 23.0 | 0.03 | 4.5 – 6.5 | 0.14 – 0.2 | Bal |
| S32205 | Density | Melting Point | Yield Strength (0.2%Offset) | Tensile Strength | Elongation |
| 7.8 g/cm3 | 1350 °C (2460 °F) | Psi – 80000 , MPa – 550 | Psi – 116000 , MPa – 800 | 15 % |
| Grade | Duplex Steel UNS S31803 / S32205 |
| Specifications | ASTM A 479 ASME SA 479 |
| Dimension | DIN, ASTM, BS and all International Standards |
| Length | 3mm to 200mm |
| Size | M3 – M56 | 3/6″ to 2″ | Custom Sizes |
| Types | Threaded Rod, Class A double ended stud, Tie Rod, Double Ended Stud, Stud Bolts, Bronze Hex Studs, Threaded Studs etc |
To satisfy our clients needs by providing high quality products at competitive price as per the schedule and to maintain long term relationship with our clients.
Duplex Steel S32205 Stud Bolts are used in marine engineering, offshore platforms, and chemical processing plants where there is high chloride exposure and mechanical stress. In oil and gas industries, they are suitable for pressure vessels, heat exchangers, and storage tanks. In desalination systems and pulp & paper mills, they provide resistance to pitting and crevice corrosion. Their corrosion resistance and strength also render them appropriate for use in power plant parts, pipelines, and water treatment plants. With better fatigue and impact strength, S32205 stud bolts guarantee long-term performance in structurally challenging and corrosive environments.
At Brian Fasteners, Duplex Steel Stud Bolts S32205 are meticulously packaged to ensure maximum protection and integrity during transit. Each bolt is carefully inspected and wrapped in protective materials to prevent damage and corrosion. Our packaging solutions include sturdy boxes and, when necessary, custom pallets to secure the products. Detailed labeling and documentation are provided to ensure easy handling and traceability. This commitment to quality packaging ensures that our fasteners arrive in optimal condition, ready for immediate use.
Brian Fasteners is a leading manufacturer and supplier of high-quality fasteners in Houston , USA, with over 8 years of experience serving global industries.
