Home > Stainless Steel 316h Stud Bolts
Request For Our Latest Prices On Stainless Steel 316h Stud Bolts in Houston , USA!
Brian Fasteners provides top-quality Stainless Steel 316H stud bolts, engineered for exceptional performance in extreme environments. Known for their superior corrosion resistance and high-temperature stability, these stud bolts are ideal for applications in marine, chemical, and aerospace industries. Manufactured to stringent industry standards, our 316H stud bolts ensure reliable performance and durability under heavy loads and harsh conditions. With a commitment to quality and precision, Brian Fasteners delivers robust solutions that meet the highest requirements for strength, resilience, and long-term reliability.
Based in Houston, USA, Brian Fasteners is a top producer and supplier of high-end stainless steel 316H stud bolts that are designed to withstand corrosion and have remarkable strength in hot conditions. Our 316H stud bolts are perfect for demanding industrial applications because they are made to resist thermal cycling and severe chemical exposure. These fasteners are made to international standards and with meticulous quality control, providing exceptional durability and weldability. Brian Fasteners offers dependable fastening solutions for power plants, chemical processing, and the marine industries that need strong and durable stainless steel components. They guarantee customised sizing, competitive pricing, and prompt delivery.
| Fasteners Material Specification | ASTM A194, ASME SA193, UNS S31609 Bolts |
|---|---|
| Standard | DIN, UNI, ISO, JIS, GB, IS, BS, ASME, ANSI, ASTM and all International Standards |
| Fasteners/ Bolts Size | M2, M2.5, M3, M4, M5, M6, M8, M10, M12, M14, M16, M20, M24, M30, M36 to M160 |
| Length | 3 mm to 200 mm |
| Bolts, Studs Threads: | METRIC, BSW, BSF, UNC, UNF or as required |
| SS 316h Fasteners Standard: | ANSI – American National Standards Institute
|
| Source of raw materials | Tata Steel, JSPL, RINL, Usha Martin, Dhamm Steel, Mukund Steel etc. |
| SCOPE OF MANUFACTURE |
|
| Fasteners In Form of: | Hex, Square, Round, Threading as per Gauge Etc. |
| Head drive: | Phillips, Slotted, Phillips/Slot, Six-Lobe, etc |
| bolting Test Certificate: | Manufacturer Test Certificate as per EN 10204 / 3.1 |
| Fasteners finishing: | Zinc (yellow, white, blue, black), black oxide, Geometry, Dacroment, anodizing, nickel plated, plated zinc-nickel, Stainless steel: Passivated Self-Colour, Hot Dip Galvanised (HDG), Bright Zinc Plated (BZP), Sherardized, Stainless Steel, Mechanically Applied coating and some special one like DACROMET |
| Production process | M2-M24: Cold Froging, hot forging M24-M100, machining and CNC for Customized connecting element |
| bolting materials Surface Coating: |
|
| Popular Types of SS 316h Bolts | Hex Bolts, Flange Bolts, Hex Head Bolts, Lag Bolts, Square Bolts, Eye Bolts, U Bolts, T Bolts, Counter sunk Bolts etc. |
| Popular Types of SS 316h Nut | Hex Head Nut, Eye Nut, Dome Nut, Wing Nut, T Nut, Panel Nut, Lock Nut, Coupling Nut, Square Nut, Acorn Nut etc. |
| Popular Types of SS 316h Screw | Hex Head Cap Screws, Socket Set Screws, Anchor Screws, Blind Rivet, Socket Head Screws, Concrete Screws, Shoulder Screws, Panel Screws, Threaded Screws, Machine Screws etc. |
| Popular Types of SS 316h Washer | Machine Washers, Flat Washer, Star Washers, Sealing Washer, Lock Washer, Split Washer etc. |
| Our stockyad location for fast delivery in India | Noida, Bengaluru, Pimpri-Chinchwad, Thiruvananthapuram, Tirunelveli, Vasai, Dhanbad, Chennai, Agra, Nagpur, Hyderabad, Kolkata, Coimbatore, Pune, Jaipur, Tiruchirappalli, Shivamogga, Ahmedabad, surat, Bhubaneswar, Thane, Nashik |
| Fasteners Packing: | IN BULK: canton, pallet, Small Boxs / carton / pallet, or customer request |
|
Grade |
C |
Mn |
Si |
P |
S |
Cr |
Mo |
Ni |
N |
|
|
316H |
Min |
0.04 |
0.04 |
0 |
– |
– |
16.0 |
2.00 |
10.0 |
– |
|
max |
0.10 |
0.10 |
0.75 |
0.045 |
0.03 |
18.0 |
3.00 |
14.0 |
– |
|
Grade |
Tensile Str
(MPa) min |
Yield Str
0.2% Proof
(MPa) min |
Elong
(% in 50mm) min |
Hardness |
|
|
Rockwell B (HR B) max |
Brinell (HB) max |
||||
|
316H |
515 |
205 |
40 |
95 |
217 |
To satisfy our clients needs by providing high quality products at competitive price as per the schedule and to maintain long term relationship with our clients.
Stainless steel 316H stud bolts have a higher carbon content of 0.04–0.10% than 316L, which improves high-temperature strength, and roughly 16–18% chromium, 10–14% nickel, and 2–3% molybdenum. At high temperatures, this grade of austenitic stainless steel provides exceptional resistance to oxidation, pitting, and crevice corrosion. Tensile strength typically falls between 515 and 690 MPa, yield strength is between 205 and 275 MPa, and elongation is between 35 and 40 percent. 316H stud bolts are appropriate for demanding environments because of their higher carbon content, which enhances mechanical stability and creep resistance under extended heat exposure.
In industries where high strength and resistance to corrosion at high temperatures are essential, stainless steel 316H stud bolts are widely used. Boilers, pressure vessels, heat exchangers, offshore platforms, chemical and petrochemical processing, and power generation plants are examples of common applications. These stud bolts ensure structural integrity in challenging conditions by performing well in environments subjected to acids, chlorides, and thermal cycling. They are perfect for welded components and high-temperature service because of their exceptional creep resistance and mechanical stability. For tough industrial and maritime applications, Brian Fasteners’ 316H stud bolts offer reliable fastening solutions.
